Dolby Digital is the common version containing up to six discrete channels of sound. The most elaborate mode in common use involves five channels for normal-range speakers (20 Hz – 20,000 Hz) (right, center, left, right surround, left surround) and one channel (20 Hz – 120 Hz allotted audio) for the subwoofer driven low-frequency effects. Mono and stereo modes are also supported. AC-3 supports audio sample-rates up to 48 kHz. The LaserDisc version of Clear and Present Danger featured the first home theater Dolby Digital mix in 1995.
This format has different names:
- Dolby Digital
- DD (an abbreviation for Dolby Digital, often combined with channel count; for instance, DD 2.0, DD 5.1).
- AC-3 (Audio Codec 3, Advanced Codec 3, Acoustic Coder 3).
- ATSC A/52 (name of the standard).
Dolby Digital Live
Dolby Digital Live (DDL) is a real-time encoding technology for interactive media such as video games. It converts any audio signals on a PC or game console into a 5.1-channel 16-bit/48 kHz Dolby Digital format at 640 kbit/s and transports it via a single S/PDIF cable. A similar technology known as DTS Connect is available from competitor DTS.
An important benefit of this technology is that it enables the use of digital multichannel sound with consumer sound cards, which are otherwise limited to digital PCM stereo or analog multichannel sound because S/PDIF over RCA, BNC, and TOSLINK can only support two-channel PCM, Dolby Digital multichannel audio, and DTS multichannel audio. HDMI was later introduced, and it can carry uncompressed multichannel PCM, lossless compressed multichannel audio, and lossy compressed digital audio. However, Dolby Digital Live is still useful with HDMI to allow transport of multichannel audio over HDMI to devices that are unable to handle uncompressed multichannel PCM.
Dolby Digital Live is available in sound cards using various manufacturers' audio chipsets. The SoundStorm, used for the Xbox game console and certain nForce2 motherboards, used an early form of this technology. DDL is available on motherboards with codecs such as Realtek's ALC882D, ALC888DD and ALC888H. Other examples include some C-Media PCI sound cards and Creative Labs' X-Fi sound cards whose drivers have enabled support for DDL.
Dolby Digital EX
Dolby Digital EX is similar in practice to Dolby's earlier Pro-Logic format, which utilized matrix technology to add a center surround channel and single rear surround channel to stereo soundtracks. EX adds an extension to the standard 5.1 channel Dolby Digital codec in the form of matrixed rear channels, creating 6.1 or 7.1 channel output.
Dolby Digital Plus
E-AC-3 (Dolby Digital Plus) is an enhanced coding system based on the AC-3 codec. It offers increased bitrates (up to 6.144 Mbit/s), support for more audio channels (up to 13.1), and improved coding techniques (only at low data rates) to reduce compression artifacts, enabling lower data rates than those supported by AC-3 (e.g. 5.1-channel audio at 256 kbit/s). It is not backward compatible with existing AC-3 hardware, though E-AC-3 decoders generally are capable of transcoding to AC-3 for equipment connected via S/PDIF. E-AC-3 decoders can also decode AC-3 bitstreams. Only the discontinued HD DVD system directly supported E-AC-3, though Blu-ray Disc offers E-AC-3 as an option to graft added channels onto an otherwise 5.1 AC-3 stream, as well as for delivery of secondary audio content (e.g. director's commentary) that is intended to be mixed with the primary audio soundtrack in the Blu-ray Disc player.
Dolby TrueHD, developed by Dolby Laboratories, is an advanced lossless audio codec based on Meridian Lossless Packing. Support for the codec was mandatory for HD DVD and is optional for Blu-ray Disc hardware. Dolby TrueHD supports 24-bit, 96 kHz audio channels at up to 18 Mbit/s over 14 channels (HD DVD and Blu-ray Disc standards currently limit the maximum number of audio channels to eight). It supports metadata, including dialog normalization and Dynamic Range Control.
The Atmos technology allows for an unlimited number of audio tracks to be distributed to theaters for optimal, dynamic rendering to loudspeakers based on the theater capabilities. That is, Atmos enables the re-recording mixer (using a special version of industry-standard Pro Tools digital audio workstation software) to designate a particular location in the theater, as a three-dimensional volume.
